Tango
¡Próximamente!
TANGO will be the most comfortable glider designed for the pilot who wants XC. The Smart nose system is applied to TANGO.
Tango has special riser system and Smart Nose System designed by unique idea of Davinci Gliders. We hope you will enjoy a safe and enjoyable flight with the high quality and durable fabrics and materials in optimal designing technology.
Technical data
| XS | S | M | L | |
|---|---|---|---|---|
| Flat area, sq.m | 21.0 | 22.9 | 24.8 | 26.8 |
| Flat A.R. | 6.3 | |||
| Flat span, m | 11.5 | 12.0 | 12.5 | 13.0 |
| Projected area, sq.m | 18.0 | 19.7 | 21.3 | 23.0 |
| Projected A.R. | 4.93 | |||
| Projected span, m | 9.43 | 9.85 | 10.25 | 10.66 |
| Cells, total | 66 | |||
| Cells, closed | 12 | |||
| Flattening, % | 14 | |||
| Cord max, m | 2.21 | 2.31 | 2.41 | 2.50 |
| Cord average, m | 1.83 | 1.91 | 1.98 | 2.06 |
| Lines height, m | 7.11 | 7.41 | 7.73 | 8.03 |
| Accelerator travel, mm | 165 | |||
| Takeoff weight, kg | 60-85 | 70-95 | 85-105 | 95-120 |
| Glider weight, kg | 3.9 | 4.1 | 4.56 | 4.8 |
| Certification | EN-C(Plan) | EN-C | EN-C | EN-C |
Materials
| Manufacturer | Material | |
|---|---|---|
| Upper surface leading edge | Dominico | 20D MF 34g |
| Upper surface except leading edge | Porcher IND | E3W 32g |
| Bottom surface | Porcher IND | E3H 27g |
| Ribs, supported | Dominico | 30D FM |
| Ribs, unsupported | Dominico | 30D FM |
| Diagonal ribs | Dominico | 30D FM |
| Lines, upper cascades | EDELRID | 8000U-70/50/30 |
| Lines, middle cascades | EDELRID | 8000U-130/90/70 |
| Lines, main (lower) cascades | EDELRID | 8000U-280/230/190 |
| Lines, upper stabilo cascade | EDELRID | 9200-30 |
| Lines, middle stabilo cascade | EDELRID | 8000U-70 |
| Lines, upper brake cascade | EDELRID | 8000U-50 |
| Lines, middle brake cascade | EDELRID | 8000U-90/70 |
| Lines, main (lower) brake cascade | EDELRID | 10N-200 |
| Risers, webbing | Guth&Wolth GMBH - Germany | 12mm zero stretch polyester webbing |
| Lines, main (lower) stabilo cascade | EDELRID | 8000U-130 |
