Breakthrough in safety and performance innovation

MAMBO – Precision and Performance in Class EN-C class

MAMBO was born with a special profile developed during Davinci's OPERA 2 design process.
The dynamically optimized profile shape is designed to minimize drag during acceleration and maximize lift. The air intake is located a little further back and is designed to reduce drag during acceleration, improve stall recovery and greatly increase collapse resistance. This is a unique Davinci design not found in any other paraglider.

All Davinci models are equipped with Davinci's exclusive SN and SN+ systems. The newly developed MAMBO adds SSS for the first time, the ultimate solution for extra stability and quick recovery.

SSS is a kind of longitudinal and horizontal frame of the profile. The shape memory alloy (Nitinol) wire is positioned in the shape of a snake, so it always maintains the shape of the profile and provides quick recovery in case of collapse. The Smart Snake System (SSS) will help you harness your racing instincts and free you from the fear of collapse in unstable weather.

Designer's note
MAMBO is designed for maximum achievable performance in EN-C class. This process was laborious and took a long time.We set the bar high and did not want to compromise. Many designs, many modifications, many tests, and many times back to the drawing board. We were not satisfied until our design was excellent in all areas and we were convinced that we could market an interesting wing that would exceed the pilot's expectations in all areas.

Technologies
This is Davinci's new airfoil concept, not found in any other glider! All Davinci models are equipped with our own developed systems, SN and SN+. With the Mambo we now introduce our newly developed system: SSS (Smart Snake System), this is the latest target for extra stability and fast recovery.
SSS is like the longitudinal and horizontal frame of the profile. The shape memory alloy (Nitinol wire) is placed in the shape of a snake so that it always maintains the shape of the profile and ensures fast recovery in case of collapse. Which are almost impossible to induce because of SSS. SSS will help you take advantage of your running instinct and free you from the fear of collapses in unstable weather.

Target groups

  • C-Class pilots who are not completely satisfied with the performance of their current wing.
  • Pilots who want to progress in the sport but feel comfortable in a C wing and do not want to move up to the D class.
  • Experienced B pilots who have been flying in this class for a long time and want to achieve maximum performance improvement.
  • D Class pilots who want to return to C Class without sacrificing performance.
Hike & Fly
9%
Waggas
50%
Fun flying
50%
XC
97%
XC Competitions
96%

SNI

Smart Nose Intakes

SN+

Smart Nose Plus

OPS

Optimized Profile Stress

DOP

Dust Out Pocket

TMR

Trailing edge Mini Ribs

OFA

Optimal Flow Analysis / Optimale flow analyse

SSS

Smart Snake System

SDL

Smart Double Layer

Delivered with Your glider

Specifications

SizeXSSML
Flat area, sq.m20.722.624.526.5
Flat A.R.6.66.66.66.6
Flat span, m11.712.212.713.2
Projected area, sq.m17.118.620.221.9
Projected A.R.4.74.74.74.7
Projected span, m8.979.379.7510.14
Cells, total67676767
Cells, closed12121212
Flattening, %17.517.517.517.5
Cord max, m2.172.272.362.46
Cord average, m1.771.851.932.00
Lines height, m6.767.067.357.64
Accelerator travel, mm140170170170
Glider weight, kg4.75.05.35.6
Takeoff weight, kg60-8570-9585-10595-120
Certification*EN-CEN-CEN-CEN-C

Components

Upper surface leading edgeMyeongjinMJ 32 MF
Upper surface Middle/TailingMyeongjinMJ 32 MF
Bottom surfacePORCHER INDE3H 27g
Ribs, unsupportedMyeongjinMJ 32 HF
Profile LoadingMyeongjinMJ 32 HF
Diagonal ribsMyeongjinMJ 32 HF
Lines, upper cascadesEDELRID8000U 90/70/50//9200-030
Lines, middle cascadesEDELRID8000U 190/130/90/70
Lines, main (lower) cascadesEDELRID8000U 360/190/070
Lines, upper stabilo cascadeEDELRID8000U 50
Lines, main (lower) stabilo cascadeEDELRID8000U 130
Lines, upper brake cascadeEDELRID8000U 130
Lines, middle brake cascadeEDELRID8000U 90/70
Lines, main (lower) brake cascadeEDELRIDA10N-200
Risers, webbingGUTH&WOLF GMBH12mm zero stretch polyester
Risers, pulleysRonstanRF25109
