Pro tandem

Duet#

Pro tandem for rough use

The best is now even better! All advantages of the well known Duet plus the new reinforced construction. Dokdo 30 DMF for the leading edge and Skytex 38 for the rest of upper surface will withstand thousands of takeoffs and landings.

Pro tandem pilots always ask for easy takeoff. Not an easy task for a rough, heavy duty wing weighting around 8 kg, but we did it! The famous takeoff of the Duet is here again despite the increased mass and durability. This new heavy duty design also incorporates many small improvements compared to the "regular" Duet. New placement of plastic rods for longer lifetime, shorter risers for better ergonomics and other small details which give you more reliability, less risk and much more fun.

Once in the air, this new Duet# also bears all the best from the Duet pedigree. Perfect turn, sweet performance and long brake travel are still here.

i-Vortex Tips (AVT) the DUET# has a very long brake travel.

DUET#: more durability, more fun.

SNI


Smart Nose Intakes

RLE


Rigid Leading Edge

OPS


Optimized Profile Stress

AVT


Anti-Vortex Tips

DOP


Dust Out Pocket

OFA


Optimal Flow Analysis

Technical data

SML
Flat area, sq.m344244
Flat A.R.5.4
Flat span, m13.814.915.3
Projected area, sq.m30.536.037.8
Projected A.R.3.94
Projected span, m11.011.912.2
Cells, total54
Cells, closed10
Flattening, %14
Cord min, m0.680.740.76
Cord max, m3.253.533.62
Cord average, m2.582.802.89
Lines height, m8.229.049.26
Trims travel, mm110
Takeoff weight, kg90-180120-230130-248
Glider weight, kg6.67.98.5
CertificationEN B

Materials

ManufacturerMaterial
Upper surface leading edgeDominico30D MF
Upper surface except leading edgePorcher Ind.Skytex 38
Bottom surfacePorcher Ind.Skytex 32
Ribs, supportedPorcher Ind.E29A
Ribs, unsupportedDominico30D FM
Diagonal ribsPorcher Ind.E29A
Lines, upper cascadesLirosPPSL 120/160
Lines, middle cascadesLirosPPSL 160/200
Lines, main (lower) cascadesEdelrid7343-420/280
Lines, upper stabilo cascadeLirosPPSL 120
Lines, middle stabilo cascadeLirosPPSL 120
Lines, upper brake cascadeLirosDSL 70
Lines, middle brake cascadeLirosPPSL 120/200
Lines, main (lower) brake cascadeEdelrid7850X-240
Risers, webbingGuth&Wolf GMBH20mm webbing
ThreadCoats Thread Thailand210D/3, 420D/3
Lines, main (lower) stabilo cascadeEdelrid6843-160
